Product Numbers:20136916933
Price:To be discussed
Product introduction:MPI Flaw Detector, Flaw Detector
It is a general-purpose MPI Flaw Detector dedicated for medium and large size working pieces such as ferromagnetic mechanical parts.
Features and Functions:
AC magnetization, near-surface flaw detection, convenient demagnetization;
Equipped with cut down phase control applying method of continuation and residual field method for flaw detection;
Resultant magnetization, AC automatic attenuation and remanence method demagnetization;
Electrical, pneumatic or manually pedaling;
Controllable silicon adjusting, continuous adjustable current, overvoltage and over temperature protection;
TRMS of AC;
Automatic tracking of magnetization current and automatic compensation.
CJW-XD MPI Flaw Detector Technical Parameters:
Model |
CJW-XD1000 |
CJW-XD2000 |
CJW-XD4000 |
CJW-XD6000 |
CJW-XD9000 |
CJW-XD12000 |
Current |
1000A |
2000A |
4000A |
6000A |
9000A |
12000A |
Magnetic Potential |
5000AT |
10000AT |
16000AT |
20000AT |
25000AT |
30000AT |
0—1000 |
0—1500 |
0—2000 |
0—2500 |
0—3000 |
0—3600 |
|
Demagnetization Performance |
<2mT |
<2mT |
<2mT |
<2mT |
<2mT |
<2mT |
Power |
380V60A | 380V100A | 380V180A | 380V300A | 380V450A | 380V600A |
